sound trigger
Found In
Invention Kit, Makerspace Kit
INPUT
Meet the sound trigger Bit
How the sound trigger Bit works
The sound trigger has a microphone that measures how much noise is around it. When the noise goes above a certain level, the sound trigger will send out an on or 5 volt signal to the following Bits in the circuit. Use the adjustment slider to set the sensitivity (how much noise is needed to trigger your Bit).
Geek Speak: the sound trigger Bit
This i20 sound trigger bit uses a microphone to detect audio. The audio signal from the microphone is first amplified to increase the sensitivity of the module. Next, the signal is passed through a circuit that behaves similarly to our timeout module: when the peaks from the microphone are higher than the detection threshold, the output is set high. Once the microphone signal drops below the threshold, the output returns low again.
